Ultra-High Brightness Open Frame Display
Ultra-High Brightness Open Frame Display, 2500 nits Sunlight Readable LCDs with 110°C High Tni LC, Wide Working Temperature for Outdoor Use, EVSE HMI Solution
21.5”, 24”, 32”, 37”, 43”, 49.5”, 55” & 65” High Brightness Open Frame Displays, Designs for Effortless Integration, Endless Applications. Designed & Assembled by Vivisign, Powered by AUO/BOE High Tni LC OC
LOW REFLECTION FOR SUPERIOR READABILITY
The WF-MH series displays adopt the Quarter Wave Plate (QWP) polariser with a low reflection solution to enhance the visibility and colour vibrancy of the display for outdoor applications.
AN EASY-TO-MOVE SENSOR BOARD FOR IR & LIGHT
The IR light and ambient light sensor board can be easy-to-move and easy to be fixed to suit different outdoor environments
LANDSCAPE/PORTRAIT CAPABILITY
The WF-MH series displays are signage-friendly and can perfectly fit either in a landscape or in a portrait mode to experience complete screen orientation flexibility and fulfill the need in different scenarios.
RESOURCES
Ultra-High Brightness Open Frame Displays
Backlight by Vivisign, Powered by AUO/BOE Industrial Grade OC (110°C High Tni LC)
(Flexible, Versatile, and Reliable | Fit for Any Enclosure)
21.5” High Brightness Open Frame Display | WF22MH
• Size: 21.5” • OC: AUO Open Cell (110 °C high Tni LC) • Back Light Type: D-LED • Resolution: 1920 x 1080 • Display Area (mm): 476 x 267.786 • Surface Treat.: Hard coating • Brightness: 2000 nits (Typ.), 2500 nits Max. • Contrast Ratio: 1000:1 • Color: 16.7M, 99% sRGB • Working Temp.: -20 – 75°C • OPT.1: LCD Monitor with HDMI IN • OPT.2: Integrated with Android Player • Outline Size (mm): 497.8 x 289.6 x 56
23.8” High Brightness Open Frame Display | WF24MH
• Size: 23.8” • OC: BOE Open Cell (103 °C high Tni LC) • Back Light Type: D-LED • Resolution: 1920 x 1080 • Display Area (mm): 527.9 x 297.8 • Surface Treat.: AG Haze 25% • Brightness: 2000 nits (Typ.), 2500 nits Max. • Contrast Ratio: 1000:1 • Color: 16.7M, 72% NTSC • Working Temp.: -20 – 75°C • OPT.1: LCD Monitor with HDMI IN • OPT.2: Integrated with Android Player • Outline Size (mm): 561.04 x 330.46 x 56
27” High Brightness Open Frame Display | WF27MH
• Size: 27” • OC: BOE Open Cell (105 °C high Tni LC) • Back Light Type: D-LED • Resolution: 1920 x 1080 • Display Area (mm): 597.888(W) × 336.312(H) • Surface Treat.: AG Haze 25% • Brightness: 1500 nits (Typ.) • Contrast Ratio: 1000:1 • Color: 16.7M, 72% NTSC • Working Temp.: -20 – 60°C • OPT.1: LCD Monitor with HDMI IN • OPT.2: Integrated with Android Player • Outline Size (mm): 626(W) × 363.8(H) × 48(D)
31.5” Sunlight Readable Display | WF32MH
• Size: 31.5” • OC: AUO Open Cell (110 °C high Tni LC) • Back Light Type: D-LED • Resolution: 1920 x 1080 • Display Area (mm): 698.4 x 392.85 • Surface Treat.: Hard Coating • Brightness: 2000 nits (Typ.), 2500 nits Max. • Contrast Ratio: 4000:1 • Color: 16.7M, 72% NTSC • Working Temp.: -20 – 70°C • OPT.1: LCD Monitor with HDMI IN • OPT.2: Integrated with Android Player • Outline Size (mm): TBD
37” High Brightness Open Frame Display | WF37MH
• Size: 37” (Half of Full HD) • OC: AUO Open Cell (110 °C high Tni LC) • Back Light Type: D-LED • Resolution: 1920 x 540 • Display Area (mm): 904.32 x 254.34 • Surface Treat.: Hard coating • Brightness: 2000 nits (Typ.) • Contrast Ratio: 4000:1 • Color: 16.7M, 72% NTSC • Working Temp.: -20 – 70°C • OPT.1: LCD Monitor with HDMI IN • OPT.2: Integrated with Android Player • Outline Size (mm): 948.1 x 254.3 x 56
43” High Brightness Open Frame Display | WF43MH
• Size: 43” • OC: AUO Open Cell (110 °C high Tni LC) • Back Light Type: Direct • Resolution: 1920 x 1080 • Display Area (mm): 940.896 x 529.254 • Surface Treat.: Hard Coating • Brightness: 2000 nits (Typ.), 3000 nits Max. • Contrast Ratio: 4000:1 • Color: 16.7M, 72% NTSC • Working Temp.: -20 – 70°C • OPT.1: LCD Monitor with HDMI IN • OPT.2: Integrated with Android Player • Outline Size (mm): TBD
46” High Brightness Open Frame Display | WF46MH
• Size: 46” • OC: AUO Open Cell (110 °C high Tni LC) • Back Light Type: Direct • Resolution: 1920 x 1080 • Display Area (mm): 1018.08 x 572.67 • Surface Treat.: Hard Coating • Brightness: 2000 nits (Typ.), 3000 nits Max. • Contrast Ratio: 4000:1 • Color: 16.7M, 72% NTSC • Working Temp.: -20 – 70°C • OPT.1: LCD Monitor with HDMI IN • OPT.2: Integrated with Android Player • Outline Size (mm): TBD
49” High Brightness Open Frame Display | WF49MH
• Size: 49” • OC: LG Open Cell (110 °C high Tni LC) • Back Light Type: Direct • Resolution: 1920 x 1080 • Display Area (mm): 1073.78(W) × 604(H) • Surface Treat.: Hard Coating • Brightness: 2500 nits (Typ.), 3000 nits Max. • Contrast Ratio: 1200:1 • Color: 16.7M, 72% NTSC • Working Temp.: -20 – 70°C • OPT.1: LCD Monitor with HDMI IN • OPT.2: Integrated with Android Player • Outline Size (mm): TBD
